FDP09 Flame Retardant Double Sided Tape UL94 VTM0 0.15mm Acrylic Tape
- UL94 VTM0 flame retardant rating ensures reliable fire safety performance
- Double-sided acrylic adhesive provides strong and stable bonding strength
- Non-woven fabric carrier improves flexibility and surface conformability
- Withstands up to 100°C for stable performance in heat environments
- Suitable for die cutting and efficient industrial production processing
FDP09 A 0.15mm Flame Retardant Double Sided Tape
FDP09-AE is a 0.15mm flame retardant double sided acrylic adhesive tape designed for industrial bonding and safety critical applications. It uses a non-woven fabric carrier combined with flame retardant acrylic adhesive on both sides.In addition, it features a double PE release liner for stable processing and easy die-cutting. Therefore, it is suitable for automated production and precision assembly applications.As a result, it provides reliable bonding performance while meeting fire safety requirements such as UL94 VTM0.
Product Key Features
Flame Retardant Safety Performance：The tape meets UL94 VTM0 fire resistance rating. Therefore, it provides reliable flame retardant performance in safety critical environments.
Strong Acrylic Adhesive System：Both sides use flame retardant acrylic adhesive. In addition, it delivers stable bonding strength and good initial tack for various substrates.
Non Woven Fabric Carrier：The non-woven substrate improves dimensional stability. Meanwhile, it also enhances conformability on uneven surfaces.
Good Temperature Resistance：The tape withstands up to 100°C for 30 minutes. Therefore, it performs reliably in moderate heat environments.
Excellent Processing Performance：It supports die cutting and pressure sensitive processing. As a result, it is suitable for high efficiency industrial manufacturing.
Product Specifications
| Item | Specification |
|---|---|
| Product Code | FDP09-AE |
| Thickness | 0.15 ± 0.005 mm |
| Adhesive | Flame Retardant Acrylic |
| Carrier | Non-woven Fabric |
| Liner | Double PE Release Liner |
| Color | White |
| Initial Tack | 5# ↑ (Both Sides) |
| Peel Strength | ≥ 1.8 kg/25mm (Both Sides) |
| Heat Resistance | 100°C / 30 min |
| Holding Power | ≥ 48 hr @ 80°C |
| Fire Rating | UL94 VTM0 |
| Temperature Range | -10°C to 85°C |
| Humidity Range | 0–95% RH |
| Solvent Resistance | Normal |
| Weather Resistance | Normal |
Application Areas
Product Advantages Summary
FDP09-AE combines flame retardant safety performance, stable acrylic adhesion, and non-woven structural strength. Therefore, it ensures reliable bonding in industrial and electronic applications.In addition, it supports die cutting and automated production. Meanwhile, it maintains stable performance under varying temperature and humidity conditions.Explore more adhesive tape products:
