TECHNICAL DATA SHEET HS-8010C
PRODUCT DESCRIPTION
HS-8010C is a transparent, substrate-free double-sided transfer tape utilizing a pressure-sensitive acrylic adhesive system.
Structure: Pure adhesive film without carrier substrate.
KEY FEATURES
. High adhesion strength to metals, glass, select plastics, and painted surfaces
. Resistant to static mechanical stress and creep under load
. Outstanding aging resistance against temperature extremes, UV exposure, moisture, and solvents
PRIMARY INDUSTRY APPLICATIONS
. Automotive Manufacturing
. Electronics Assembly
. Advertising & Signage
. Hardware Fabrication
. Building & Construction
STANDARD DELIVERY SPECIFICATIONS
Adhesive Layer Width (mm) Length (m)
Thickness (mm)
0.10 800 33 / 66 / 100
Note: Custom widths and lengths available upon request. Contact Anhui Heshuo for details.
PHYSICAL PROPERTIES (LABORATORY REFERENCE)
| ITEM |
UNIT |
VALUE |
REF STD |
| Adhesive Layer Thickness |
mm |
0.10±0.01–
0.02 |
GB/T7125-2014 |
| 180° Peel Adhesion (Steel Plate) (25 min dwell) |
N/25mm |
≥20 |
GB/T2792-2014 |
| Static Shear (25×25 mm)
(80 °C, 500 g load) |
hr |
≥24 |
GB/T4851-2014 |
| Temperature Resistance (Short-Term Peak) |
°C |
150 |
– |
| Temperature Resistance (Continuous Service) |
°C |
-40 to +100 |
– |
| Tape Color |
|
Transparent – |
| Liner Type |
– |
PET Film – |
Shelf Life: 12 months from shipment date in original packaging at 4–30 °C, <55% RH.
APPLICATION INSTRUCTIONS
. Bond strength depends on adhesive contact area; apply firm initial pressure to maximize bonding performance.
. For optimal results, ensure surfaces are clean, dry, and uniformly flat. Typical solvent: ethanol. Follow safety protocols when handling solvents.
. Recommended application temperature: 21–38 °C (70–100 °F). Avoid initial bonding below 10 °C (50 °F).
EXTENDED APPLICATION SCENARIOS
. Bonding interior trim badges and decorative emblems on automotive exterior/interior panels
. Mounting touchscreen display lenses onto device frames in consumer electronics assembly
. Affixing transparent acrylic signage to glass storefronts and indoor wall surfaces
. Laminating protective anti-scratch films onto elevator control interface panels
. Transfer bonding of reflective foils on traffic sign substrates in outdoor installations
DETAILED PRODUCT DESCRIPTION
. Structure: Substrate-free acrylic adhesive film enables ultra-thin bonding lines and minimizes visible edges in finished assemblies.
. Adhesive Performance: Pressure-sensitive acrylic formulation provides rapid wetting and high ultimate strength on smooth substrates.
. Stress Management: Uniform adhesive layer distributes mechanical stress evenly, reducing peel initiation risk under vibration.
. Thermal Durability: Maintains bond integrity from -40 °C to +100 °C continuous service; withstands short-term spikes to 150 °C.
. Process Compatibility: Compatible with manual and automated die-cutting; PET liner supports precise registration in high-volume production.
IMPORTANT STATEMENT
All parameter values provided by Anhui Heshuo are laboratory test results under controlled conditions and are not guaranteed specifications. Product suitability varies by end-use application. Customer must perform pre-production suitability testing and confirm fitness prior to purchase. Purchase implies customer assumes applicability risk. Anhui Heshuo will replace non-conforming goods for verified quality issues. Intellectual
property rights protected by law; unauthorized replication, imitation, or misuse is prohibited.
